S10525 Floor Heating Circulating Household Pump
Category:
Mixing water center
Summary:
Key word:
S10525 Floor Heating Circulating Household Pump
Products description
Floor Heating Circulation Pump with 3 Speeds High Efficiency for Floor Heating are designed for efficient circulation of liquids in floor heating and air systems for residential and commercial applications.
Our pumps come with three speed settings, allowing you to adjust the pump speed to meet the needs of your system and thereby reducing energy consumption and saving money.
This product is made from cast iron, and featuring a self-lubricating wet rotor design, operate whisper-quiet and maintenance-free.
It can be widely used in residential and commercial applications,domestic water heating,floor heating, radiant heating ,plumbing and so on.
Construction Materials
Pump bode cast iron
Impeller PP
Shaft Porcelain
Bearings Ceramic
Fluid temperature range: -10℃~110℃
Max. working pressure:10bar
Ambient Temperature
Permissible up to:40℃
Mains power: 1~ 230v,50Hz
Degree of protection: lp44
Insulation class: F
Outlet:3/4" or 1"or 1-1/4"
Color Notes
Due to different production batches, there are BLUE and GREEN shells,so that we will deliver them at random.If you want to specify color, please contact customer service in advance. Thanks for your understanding.
Installation Notes
-For indoor use only
-Not for submersible use
-Do not run pump dry
-Do not install the motor part above or below the pump body
