S3201N Underfloor Heating Manifold With Mixing Water Valve
Category:
Manifold series
Summary:
Key word:
S3201N Underfloor Heating Manifold With Mixing Water Valve
We use the pump mixing valve to lower the water temperature from the boiler to the underfloor heating system. This mixer is a self-acting thermostatic 2-12port (Thermostatic Mixing Valve) that is used to mix the flow from the boiler with the return from the underfloor heating system, to provide the correctly mixed temperature for the heating loops beneath your floor.
Features & Benefits
*Compact bolt on unit providing quick and simple installation
*Provides controlled mixed temperature water to underfloor heating systems
*Easy set up within the adjustable range of 35°C to 60°C
*Controls flow temperature to +/-2°C even with changing boiler flow and return temperatures
*Nickel plated control pack to match stainless steel UFH manifold
*Blanking cap and pump union can be interchanged, so the pack can be reversed
Specifications
Maximum static pressure: 10 bar
Maximum Temperature: 90°C
Adjustable control range: 35°C - 60°C
Factory per-set: 35°C
Connection sizes: 3/4" FBSP (mixer) 1"MBSP (manifold)
Mixing Control Adjustment
The thermostatic blending valve is factory set to provide water mixed at 45°c to the underfloor heating manifold. The mixed water temperature can be adjusted to suit from 35°c to 65°c by rotating the blending valve control knob, clock wise to increase the temperature and anticlockwise to reduce.
