S8209B Electric Thermal Actuator Floor Heating Valve
Category:
Actuators
Summary:
Key word:
S8209B Electric Thermal Actuator Floor Heating Valve
Thermal Actuator instruction:
Application
Electric actuator is suitable for the floor heating system, manifold lock shield and small valve, dynamic balance valve’s close and open.
Diverse water bypass valve, small valve, dynamic balance valve are as part of electric control valve.
Notice:
NC-Actuators are equipped with red mounting split on the position indicator to secure easy valve connection. When mounted this split must be removed for correct operation.
Technical Data
Supply voltage: 12V/24V/110V/220V
Power consumption: 3-4W/2-3W
Frequency: 50hz
Spindle travel time: 3-5min
Ambient Temperature: -5℃-60℃
Enclosure: IP54
Cable length: 800-1000mm
