S5101N Thermostatic Mixing Valve Pump Set For Manifolds
Category:
Combined valve
Summary:
Key word:
S5101N Thermostatic Mixing Valve Pump Set For Manifolds
Technical Specification
1.Material: Copper
2.Suitable water temperature
3.Cylinder pipe thread accord with ISO228
standards.
Mixing Control Adjustment
The thermostatic blending valve is factory set to provide water mixed at 45°c to the underfloor heating manifold. The mixed water temperature can be adjusted to suit from 35°c to 65°c by rotating the blending valve control knob, clock wise to increase the temperature and anticlockwise to reduce.
Specification
2 x Temperature gauges.
Scald safe functionality that protects underfloor heating pipes and the flooring from drastic, uncontrolled temperature rises. In the event of a cold water failure, for example, the hot water supply will shut off automatically.
Control flow temperatures to +/-3°c.
1″ BSP Male fittings for connection to the manifold.
3/4″ Female BSP fittings for connection to the heat source flow and return loops.
Pressure class PN10, working pressure 10 bar (1.0 MPa).
Maximum temperature of 95°c. Operating temperature between 30°c and 70°c.
