S3109N Circulating water pump mixing valve
Category:
Mixing water center
Summary:
Key word:
S3109N Circulating water pump mixing valve
Mixing valve details:
Material: brass
Nominal pressure: ≤10bar
Applicable medium: cold and hot water
Working temperature: t≤100℃
Temperature control range: 30~70℃
Temperature control accuracy: +/-1℃
Specifications: 1” 1-1/4”
Pump specifications:
Pump bode cast iron
Impeller PP
Shaft Porcelain
Bearings Ceramic
Fluid temperature range: -10℃~110℃
Max. working pressure:10bar
Ambient Temperature
Permissible up to:40℃
Mains power: 1~ 230v,50Hz
Degree of protection: lp44
Insulation class: F
Outlet:3/4’’ or 1’’or 1-1/4’’
Remark:
-For indoor use only
-Not for submersible use
-Do not run pump dry
-Do not install the motor part above or below the pump body
